Okinawa 54.6V 6A Lithium Battery Charger - R30, Lite

54.6V 6A battery charger with IEC 3 pin female connector for 48V lithium battery. Compatible with Okinawa R30 and Lite electric scooters.

Origin: Made in India

Warranty: 1 Year from the date of purchase

Return: 7 days Return/Replacement (Please read Refund policy for more information)

Delivery: 3-10 days

Features:

• SMPS based technology
• Forced air cooling by built in DC fan
• LED Indication for Mains ON, Charging percentage
• 100% Full Load Burn in test
• High Reliability

Mechanical Details:

• Dimension(L*W*H) : 198*115*65MM
• Weight : 1.5Kg

Specification:

Input:

• Input Voltage : 230 Vac
• Frequency : 50 Hz
• Input AC Current at 230Vac : Max 5 Amps
• Connect input mains supply cord to the 5Amp Ac plug wall socket with proper grounding
• Make sure that Earth(Ground) is connected

Output:

• Output Voltage : 54.6 V
• Output Current : 6 Amps
• Efficiency : greater than 85%
• Do not touch uninsulated output wires
• Connect the charger output cable with connector (DC OUTPUT) to the battery connector
• Make sure that Battery +ve terminal connected to +ve terminal of charger and Battery -ve terminal connected to -ve terminal of charger

 Protection:

• Output short circuit
• Over Temperature
• Output Overload
• Battery reverse protection

LED Indications:

Warranty Terms:

We provide service and care, the battery charger shall be free from the material and workmanship for 12 months from the date of original invoice.
This warranty does not include any damage to, malfunctioning or improper operation of battery charger resulting to

• If serial number is not present on unit, warranty will be void
• Abuse, misuse or tampering
• Repair or maintenance of battery charger or related equipments
• Improper connection may damage charger. means in place of AC connection DC
• Negligent use, operation, care, cleaning, storage or handling
• Fire, water, dust, wind lighting or other natural causes
• Power fluctuation due to surge

Looking for a different Okinawa charger?
→ Okinawa Praise Pro / iPraise+ Charger — Chagori Connector (2022 onwards)
→ Okinawa Praise Pro / iPraise Charger — D-Type Connector (Pre-2022 models)
→ Okinawa Ridge / Ridge+ / Dual 100 Charger 67.2V
→ Browse all Okinawa chargers

Frequently Asked Questions

Q: Is this charger only for the Okinawa R30?
A: Yes. This 54.6V 6A charger is specifically for the Okinawa R30. Do not use on Praise Pro or Ridge models which require different voltages.

Q: Will this charger damage my R30 battery if I leave it plugged in overnight?
A: No. The charger has an automatic 54.6V cut-off — it stops charging once the battery is full.

Q: My R30 charger shows a red light and is not charging. Do I need a new charger?
A: A solid red light usually means the charger is working normally (charging in progress). If the light stays red and the battery is not charging after 1 hour, the charger may be faulty and needs replacement.

Q: Is this an original Okinawa R30 charger?
A: This is a high-quality compatible replacement charger meeting OEM specifications — same voltage, same amperage, same connector type.

Q: Is this charger compatible with Okinawa R30 Lite?
A: Yes. This charger is compatible with both the Okinawa R30 and R30 Lite. Same connector, same voltage specs — direct replacement for both models.
