84V 10A Lithium Battery Charger for Okaya Faast - Chagori Connector

Reliable 84V 10A lithium battery charger for 72V Okaya Faast electric scooters. Built on SMPS technology with forced-air cooling, this is a standard replacement charger with the same Chagori 2+4 blue-ring connector as your original — plug straight in, no adapters needed.

This is the non-CAN counterpart of the Okaya Model OLBC1KWCAN — same connector, same 84V 10A output, same scooter compatibility. It charges your Okaya Faast battery reliably using a fixed CC-CV profile and will work perfectly with your scooter's charging port, just without the active BMS data dialogue of the CAN version.

Compatible Okaya Models: Okaya Faast F2B, Faast F2F, Faast F2T, Faast F3, and Faast F4 — all 72V Okaya Faast scooters using the Chagori 2+4 blue-ring charging connector. If your scooter model isn't listed, verify by matching the blue Chagori port and checking your existing charger label for "72V / 84V output" — if it matches, this charger will work.

Need the smart CAN version with active BMS communication? See our Okaya CAN Charger (Model OLBC1KWCAN) or the Okaya IP65 Waterproof CAN Charger.

⚠️ Have an IEC 3-pin connector instead of Chagori? Your scooter uses a different charging port — order our Okaya Faast Non-CAN IEC Connector charger instead.

Key Highlights:

• Origin: Made in India
• Warranty: 12 Months from the date of purchase
• Return Policy: 7 Days Return/Replacement (see Refund Policy for details)
• Delivery: 3–10 Days

Technical Features:

• SMPS-based technology for high efficiency and reliability
• Forced-air cooling via built-in DC fan
• LED indication for Mains ON and charging status
• 100% full-load burn-in tested
• High-reliability build

Mechanical Details:

• Dimensions (L×W×H): 265 × 140 × 65 mm
• Weight: 2.4 kg
• Connector Type: Chagori 2+4 (Blue Ring)
• Cooling: Forced-air (built-in DC fan)

Specification

Input:

• Input Voltage: 230V AC
• Frequency: 50 Hz
• Max Input Current: 5 Amps
• Connect to a properly grounded wall socket; ensure Earth is connected.

Output:

• Output Voltage: 84V DC
• Output Current: 10 Amps
• Efficiency: greater than 85%

Safety Instructions:

• Connect charger output to battery before switching on mains power.
• Do not touch uninsulated output wires.
• Charge in a dry, well-ventilated area; do not expose to water or rain.

Protection:

• Output Short Circuit Protection
• Over-Temperature Protection
• Output Overload Protection
• Battery Reverse Polarity Protection

Warranty Terms: Free from defects in material and workmanship for 12 months from the original invoice date. Warranty void if serial number is missing or tampered, or damage results from abuse, misuse, unauthorised repair, improper connection, or environmental damage (fire, water, dust, power surge).
